Introduction
As a leading bitumen supplier in the UAE, Raha Oil produces and exports Oxidized Bitumen 90/15 to markets across the GCC, Africa, Asia, and beyond. Manufactured by air-blowing Bitumen 60/70 under controlled conditions, this grade offers enhanced thermal stability, strong adhesion, and reliable waterproofing performance for a wide range of industrial and construction applications. Whether you need drums, Kraft bags, or carton box packing, Raha Oil delivers consistent, ASTM-tested Oxidized Bitumen 90/15 backed by full quality documentation for every shipment.
Applications of Oxidized Bitumen 90/15
Oxidized Bitumen 90/15 is widely used across construction, industrial, and specialty applications:
Construction and Waterproofing: Roofing felts and membranes, foundation damp-proofing, joint filling, and sealing saw cuts and joints where movement is minimal.
Industrial and Protective Coatings: Pipe coating and corrosion protection, bituminous marine mastic for oil and gas pipeline joints, asphalt-based paints, mastics, and damp-proofing.
Specialty Applications: Anti-slip layer compound in the piling industry, sound-dampening felts, carpet-backing, acoustic panels, and electrical cable joint protection.
Automotive Industry: Vehicle undercoating, providing excellent waterproofing, dust protection, and noise reduction.
Beyond construction, this grade is also used in chemical, fuel, paint, lacquer, varnish, paper-pulp-board, and textile processing industries, as well as in road construction, pavement repair, and general civil works, including adhesives, dust-binding agents, and raw material for rubber and plastic products.
Oxidized Bitumen 90/15 vs. Other Oxidized Grades
Oxidized Bitumen 90/15 sits among the harder grades in the Oxidized Bitumen family, with a low penetration range (10–20) similar to 105/15 or 90/10, but with a lower softening point (85–95°C) compared to 105/15 or 115/15. This combination gives it strong rigidity while remaining slightly more workable than the highest-softening-point grades, making it a practical choice for applications needing both hardness and manageable processing.
Storage and Handling Recommendations
Oxidized Bitumen 90/15 should be stored in a cool, dry area away from direct sunlight and open flames. Its high softening point allows it to remain solid and stable at ambient temperature, simplifying long-term storage. Before heating, the material should always be broken into smaller pieces to promote even heat distribution and avoid localized overheating, which can compromise both safety and product quality.
Why Oxidized Bitumen 90/15 Is Preferred for Marine and Pipeline Applications
The combination of low penetration and high softening point makes Oxidized Bitumen 90/15 particularly effective as a base material for bituminous marine mastic used in oil and gas pipeline joint sealing. Its rigidity and resistance to deformation under pressure make it well-suited to demanding offshore and industrial environments where long-term durability is critical.
Frequently Asked Questions - FAQ
It is used mainly in roofing, waterproofing, pipe coating, automotive undercoating, and bituminous marine mastic for pipeline joints.
Oxidized Bitumen 90/15 has a softening point of 85–95°C and a penetration value of 10–20 (0.1 mm), as confirmed by ASTM D36 and ASTM D5 testing.
It should be broken into pieces and heated gradually, not exceeding the maximum safe handling temperature of 230°C, to avoid localized overheating.
Steel drums, Kraft/polyamide bags, carton boxes, and jumbo bags (upon request) are available.
Yes, full technical documents including TDS, COA, and MSDS are provided.
Oxidized Bitumen 90/15 — Technical Data Sheet
ASTM Standard| Property | Test Method | Unit | Specification | |
|---|---|---|---|---|
| Specific Gravity @ 25/25°C | ASTM D70 | kg/cm³ | 1.05 approx | |
| Penetration @ 25°C | ASTM D5 | 0.1 mm | 10–20 | |
| Softening Point | ASTM D36 | °C | 85–95 | |
| Ductility @ 25°C | ASTM D113 | cm | 1.5 min | |
| Loss on Heating (wt) | ASTM D6 | % | 0.2 max | |
| Flash Point | ASTM D92 | °C | 250 min | |
| Solubility in CS2 (wt) | ASTM D4 | % | 99.5 max | |
| Spot Test | AASHTO T102 | – | Negative | |
Source: Raha Group official Technical Data Sheet, Oxidized Bitumen 90/15 (ASTM standard). Values represent standard product specification; actual batch results are confirmed via Certificate of Analysis (COA) issued with each shipment.
Why Choose Raha Oil for Oxidized Bitumen 90/15
Raha Oil manufactures Oxidized Bitumen 90/15 from Dubai, UAE, with production and testing following ASTM standards. Quality is verified through internal testing before every shipment, with full documentation — including TDS, COA, and MSDS — provided on request.
With flexible packing — from 20 kg Kraft bags to 200 kg steel drums, including palletized options — and an established export track record across the GCC, Africa, and Asia, Raha Oil supports both trial orders and large-scale industrial supply requirements for this specialized hard grade.
